$1,299.00 USD
Enjoy a $100 off on your first purchase of this product. Use the code N100 at checkout to save $100 and...
Style
  • MIRACO 16GB
  • MIRACO Pro 32GB
ecom-no-replace-4D9tstPYkvtrust-s

Complete Your Creative Journey:

Crealiy Hyper Series PLA 3D Printing Filament 1kg
$21.00
$24.99
3D Crystal Flexible Dragon in Egg Figurine Blind Box - Mystery Desktop Decoration
$12.99
$19.99

Description

Reviews

Authorized Certifications

Enjoy a $100 off on your first purchase of this product. Use the code N100 at checkout to save $100 and experience our new product.

Features:

1. High-Resolution Color Capture

The Revopoint MIRACO 3D Scanner's 48-megapixel RGB camera enables the creation of clear, high-resolution color 3D models, ensuring detailed and sharp imaging.

2. Light weight, High Precision

The MIRACO, weighting 750g, is a portable standalone device. It achieves an accuracy of up to 0.05mm for detailed captures and up to 0.5mm for larger surfaces.

3. Durability and Versatility

5,000 mAh battery allows for extended scanning sessions, with 6-inch 2K AMOLED touch-sensitive screen and adjustable viewing angles, function in temperatures between -10℃ and 40℃.



Specifications:

Product Name: MIRACO 3D Scanner

Technology: Quad-Camera infrared structured light

Single-frame Accuracy: up tp 0.05mm

Closest Single Capture Range: 28mmX53mm@100mm

Working Distance: 100mm-1000mm

Point Distance(Resolution): up to 0.02mm

Minimum Scan Volume: 10mmX10mmX10mm

Maximum Scan Volume: 4000mmX400mmX4000mm

Scanning Speed: up to 15 fps

Depth Camera Resolution: up to 2 Megapixels

RGB Camera Resolution: 48 Megapixels

Tracking Methods: Feature, Marker

3D Light Source: Class 1 Infrared Light

Positioning Sensors: 9-axis IMU

CPU: 8 core, 2.4GHz

Memory(RAM): 16GB or 32 GB

Storage: 256GB eMMC

Output Formats: PLY, OBJ, and STL

Compatible Systems: Windows 10/11, macOS

Wi-Fi: Wi-Fi 6



Packing List:

16GB:

1*MIRACO 3D Scanner

1*Tripod

1*Mini Turntable&Sample Bust

1*Turntable Topper& Turntable Power Cable

1*Scanner Bag

1*Near-mode Calibration Board

2*Magic Mat

1*Wrist Strap

1*Dual USB Type-C Port Power Adapter

1*USB Type-C to C Cable(1.8m)

1*Cleaning Cloth&Markers

1*Certificate&Warranty Card



32GB

1*MIRACO Pro 3D Scanner

4*Far-mode Calibration Board

1*Large Calibration-board Sheet

1*USB Type-C to HDMI Adapter

1*Tripod

1*Mini Turntable&Sample Bust

1*Turntable Topper& Turntable Power Cable

1*Scanner Bag

1*Near-mode Calibration Board

2*Magic Mat

1*Wrist Strap

1*Dual USB Type-C Port Power Adapter

1*USB Type-C to C Cable(1.8m)

1*Cleaning Cloth&Markers

1*Certificate&Warranty Card
